AUA-UNBP-630.2-0.5-OD6

Item Number7259
Angle of Incidence0 Degrees
Center Wavelength 630.2 nm Nominal
FWHM
Transmission Band(s)630.2 nm > 85% T Absolute
Blocking Level OD6
Blocking Range(s)*OD6: 400 to 628 nm, 633 to 1000 nm
Filter DesignMulti-Cavity
Substrate Type NBK-7
Dimensions25.0 mm Diameter
Filter Thickness2.0 mm
Assembly TypeUnmounted

Write your review

AUA-UNBP-630.2-0.5-OD6

AUA-UNBP-630.2-0.5-OD6

Alluxa Ultra-Narrow Bandpass Filter, 630.2 nm center wavelength, 0.5 nm FWHM and OD6 blocking. High performance with the narrowest bandwidth response.
