AUA-UNBP-532.2-0.15-OD6

Item Number7316
Angle of Incidence0 Degrees
Center Wavelength 532.2 nm +0.4 / -0.1 nm
FWHM
Transmission Band(s)Peak> 85% T Absolute
Blocking Level OD6
Blocking Range(s)*OD6: 200 to 496 nm, 569 to 1200 nm
Filter DesignSingle Cavity
Substrate Type Fused Silica
Dimensions25.0 mm Diameter
Filter Thickness5.0 mm
Assembly TypeAnodized Aluminum Ring
Assembly Thickness6.5 mm

Write your review

AUA-UNBP-532.2-0.15-OD6

AUA-UNBP-532.2-0.15-OD6

Alluxa Ultra-Narrow Bandpass Filter, 532.2 nm center wavelength, 0.15 nm FWHM and OD6 blocking. High performance with the narrowest bandwidth response.
